Fluon® PTFE FC

Fluon® PTFE FC has improved creep and wear resistance. A wide range of fillers such as glass fiber, graphite, bronze, carbon fiber and more are available.

Fluon® PTFE FC Usage

Fluon® PTFE FC Usage

The following are examples of uses for the FC grade (containing filling materials).

Gaskets, packing, V-rings

Gaskets, packing, V-rings

Piston rings

Piston rings

Bearing bushes

Bearing bushes

Grade List

PropertiesFiller Type and Content (%)Bulk DensityMedian Particle SizeTensile StrengthElongationSpecific GravityApplicationsCharacteristics
Unitsg/lμmMpa%-
PA1015SZGlass fiber (15%)88073026.2 3602.22 Bearings
Gaskets
Discs for valves
V-rings, O-rings
Plug valve seats
Pump impellers
Mechanical seals
Improved wear resistance,
Improved compression resistance,
Filler can be damaged by strong amines and hydorgen fluoride, Improved powder flow for Z-type of PA.
RB1015S510-27.9 3102.21
PA1020ZGlass fiber (20%)89066021.7 3502.24
PA1025ZGlass fiber (25%)86073018.5 3402.23
RB1025S480-25.0 3202.22
PB2015Graphite (15%)67073015.2 2002.14 Piston rings
Bearings
Gaskets
Shock absorbers
Enhanced creep resistance,
Chemical resistance,
Low coefficient of friction,
Improved load resistance
RB2015410-21.9 2752.14
PB2215HGraphite (14%)
+
Carbon fiber (1%)
68056017.2 2402.13
PB3060Bronze (60%)134076020.0 2903.85 BearingsImproved wear and creep resistance,
High conductivity because of metal filler,
Anti-oxidizing for PB3360
PB3360T133070018.0 3003.94
PB2510Carbon fiber (10%)67062025.0 3002.07 Shaft bearings
Bearings
Piston rings
Ball valve seats
Bearing pads
Oil seals
Improved wear resistance in water,
Improved load resistance,
Improved bending strength
RB2510440-30.0 3302.08
PB2515Carbon fiber (15%)65062020.5 2702.02
PB1205Glass fiber (20%)
+
Graphite (5%)
76070016.0 2502.21 Bearings
Piston rings
Mechanical seals
Ball valve seats
Improved wear resistance,
Improved creep resistance,
Improved stiffness and hardness
PB1211Glass fiber (15%)
+
Molybdenum disulfide (5%)
79070021.5 3052.27
RB1211470-25.2 3202.28
PB1202Glass fiber (16%)
+
Graphite (2%)
+
Proprietary filler (2%)
75065019.0 3002.24
PA3540LTBronze (30%)
+
Carbon fiber (10%)
94071013.5 2852.66 Bearings
Packing
Improved load resistance,
Improved wear resistance,
Improved stiffness and hardness
RA3540G620-17.1 3652.64
RA7003Proprietary filler (3%)420-33.8 3602.15 Antistatic componentsSemi-conductive
PA7115Polyimide (15%)70065017.6 3601.95 Packing
Oil seals
Improved tear resistance,
Reduced scratch occurrence

Measurement properties are based on JIS K-6891.

PA, PB : Good powder flow
RA, RB : Regular powder
S : Dark center free
Z : High bulk density, High powder flow
T : Discoloration resistance
